Magna Audio Micro-Framed Array Speakers
Keep the screen wall clean while scaling the sound to a larger room. Micro-Framed arrays bring multiple drivers into an architectural speaker format.
Price on request. Enquire for your configuration, finish and quantity. GST invoice provided. Confirm availability and India warranty before ordering.
Did you like this product? Add to favorites now and follow the product.
- GST invoice
Provided with your purchase
- System matching
Advice for your equipment and room
- Project planning
Pune, Maharashtra & India
- Purchase clarity
Confirm delivery and model warranty
AUDIOGURU · PUNE & INDIA
Make it part of the right system.
Tell us about your room, existing equipment and budget. Our Pune team can help you check compatibility, plan installation and confirm availability before you order.
Description
Micro-Framed Array Speakers
Keep the screen wall clean while scaling the sound to a larger room. Micro-Framed arrays bring multiple drivers into an architectural speaker format.
Choose the array around the room and listening positions
Start with the room drawing, seating distance and the role of each speaker. A front channel beside a screen has a different job from a background-music zone. Choose the array length and location together, with enough wall space and a practical route for speaker cables.
The longer arrays give you more drivers, but they also change the amplifier requirement and installation footprint. Use the model-specific figures below as a starting point for system design. A suitable amplifier, correct wiring and careful setup matter as much as choosing the speaker.
Compare the slimmer Nano-Framed series, consider the Micro-Framed Bandpass 8 subwoofer, or explore the Magna Audio range. AudioGuru’s Pune team can help coordinate the equipment plan and an itemised quotation for a Maharashtra or India project. Approve the final model, finish and installation drawing before construction.
Technical details and choices
| Configurations | 2D, 3D, 3DC, 6D and 12D |
|---|---|
| Design | Passive architectural linear arrays |
| Applications | Media rooms, private cinemas and distributed audio |
| Installation | Indoor in-wall integration |
| Selection | Amplifier load, output and cut-out depend on the selected model |
| 3D / 3D Cinema — drivers and amplifier | Three 3-inch full-range drivers; 120 W recommended amplification; 6 Ω. |
| 6D — drivers and amplifier | Six 3-inch full-range drivers; 240 W recommended amplification; 6 Ω. |
| 12D — drivers and amplifier | Twelve 3-inch full-range drivers; 480 W recommended amplification; 6 Ω. |
| Frequency response | 3D / 3D Cinema and 6D: 110 Hz–20 kHz; 12D: 80 Hz–20 kHz. |
| Sensitivity (1 W/1 m) | 3D / 3D Cinema: 95.5 dB SPL; 6D: 98.5 dB SPL; 12D: 101.5 dB SPL. |
| Weight | 3D and 3D Cinema: 2.10 kg each; 6D: 4.20 kg; 12D: 8.40 kg. |
| Construction and model-specific placement | Aluminium open baffle with perforated steel grille; no integrated lighting. Technical table lists 3D / 3D Cinema for wall or ceiling, and 6D / 12D for wall installation, indoors. |
| 2D and installation drawings | NEEDS CONFIRMATION: the family overview names 2D, but the current technical table covers 3D / 3D Cinema, 6D and 12D only. Confirm 2D specifications and the selected model’s dimensions, cut-out and approved drawing. |
Before ordering: The published 3D, 3D Cinema, 6D and 12D electrical figures are listed above. NEEDS CONFIRMATION: 2D specifications, final model dimensions, cut-out and approved installation drawing. In-wall soundbars described as a future roadmap are not included in this listing.
Sources: customer-supplied MAGNA catalogue, pages 12; Official Magna product information, Official Magna technical information. Checked 29 October 2026. Images show an example finish or installation; the approved quotation defines your exact product.
Request a tailored quotation
Price on request. Share the model or configuration, quantity, preferred finish, room or garden plan and delivery PIN code. We will confirm the supplied equipment, availability and India warranty. Amplifiers, cabling, mounting, lighting accessories, delivery and installation are included only when listed in your quotation.
AudioGuru provides GST invoices. Our Pune team helps with system matching and project planning, with Pune and Maharashtra as our core installation areas. Projects elsewhere in India are arranged according to location and scope.
Frequently asked questions
Can every Micro-Framed array be fitted in the ceiling?
The official technical table lists 3D and 3D Cinema for indoor wall or ceiling installation. It lists 6D and 12D for indoor wall installation. Confirm the exact model and mounting arrangement on the project drawing; do not assume the same installation options apply to every array.
Additional information
| Manufacturer | Magna Audio |
|---|
